Digital Force Gauges Series ДЦ-0,5

M5-012

MARK-10

New product

Digital push pull gauge Mark-10 with measuring range 0.5N pass metrological control in accredited lSO 1700.5 laboratory.

More details

Download

Специфікація динамометри

Сертифікат дистриб'ютора MARK10

Product Videos



120 960,00грн

Data sheet

Country of manufacture USA
Range, N less than 10
Measuring range ,mm 0,5H
Digital indication +
Data output USB,RS-232
Дискретность , H 0,0001
Scales lbF, kgF, N
Accuracy, % 0,1%

More info

  • Accuracy: ±0.1% of full scale
  • Sampling rate: 7,000 Hz
  • Power: AC or rechargeable battery. Multi-step low battery indicator is displayed, gauge shuts off automatically when power is too low.
  • Battery Life:
    - Backlight on: up to 7 hours of continuous use
    - Backlight off: up to 24 hours of continuous use
  • Measurement units: lbF, ozF, gF, kgF, N, kN, mN (depending on model)
  • Outputs:
    - USB / RS-232: Configurable up to 115,200 baud. Includes Gauge Control Language 2 for full computer control.
    - Mitutoyo (Digimatic): Serial BCD suitable for all Mitutoyo SPC-compatible Devices.
    - Analog: ±1 VDC, ±0.25% of full scale at capacity.
    - General purpose: Three open drain outputs, one input.
    - Set points: Three open drain lines.
    - Safe overload: 150% of full scale (display shows “OVER” at 110% and above)
  • Weight:
    - M5-012 - M5-100: 1.0 lb [0.45 kg]
    - M5-200 - M5-500: 1.2 lb [0.54 kg]
    - M5-1000 - M5-2000: 1.8 lb [0.82 kg]
  • Included items: Carrying case, chisel, cone, V-groove, hook, flat, extension rod, universal voltage AC adapter, battery,
    quick-start guide, USB cable, resource CD (USB driver, MESURTMLite software, MESURTMgauge DEMO software, and user's guide), NIST-traceable certificate of calibration with data
  • Warranty: 3 years (see individual statement for further details)
  • All Mark-10 digital force gauges pass  metrological control in accredited lSO 17025 laboratory.
